Injection Water Treatment
Proven solutions for offshore injection water treatment.
Guarantee safe and reliable enhanced oil recovery (EOR) operation with high quality injection water treatment
The prevention of sulfate precipitation and souring in the injection well or reservoir is a major concern for oil and gas producers. Mitigating reservoir scaling and souring allows producers to extract more oil from wells, reduce costs, protect downstream equipment, and mitigate safety and environmental risks. DuPont Water Solutions provides membranes that can be used in various steps of injection water treatment systems to improve oil recovery.
Oil & Gas - Injection Water Brochure
Learn about our innovative membrane technologies to effectively treat injection water.
View all product data sheets for our injection water treatment products.
Proven solutions for offshore injection water treatment
Learn more about our innovative membrane technologies to treat injection water. Pretreatment Sulfate Removal Nanofiltration Desalination for Low-Salinity Injection
Pretreatment with ultrafiltration for reliable downstream operation
Proper pretreatment is a key factor for successful long-term performance of sulfate removal units (SRUs). Reliable pretreatment can remove particles, algae, bacteria, and sand to provide effective and stable operation downstream, reducing downtime. DuPont offers a variety of ultrafiltration (UF) products that are advantageous in meeting these needs.
DuPont offers UF in two different configurations: multi-element vessel (MEV) or single-element racks. The MEV system uses a pressure vessel with an adaptor to hold multiple UF modules operating in parallel. This reduces the amount of space needed and eliminates the need for piping manifolds. DuPont also offers UF cartridges that can fit into standard horizontal pressure vessels that are organized similarly to an RO system. This offering is a more flexible option for pre-built systems.
DuPont also offers UF modules with either polyvinylidene fluoride (PVDF) or polyethersulfone (PES) fibers. PVDF membranes are most common in oil & gas applications as they offer high chemical tolerance and are tolerant to temperature variations, promoting longer module life. Hollow-fiber PVDF membranes provide exceptionally high filtrate quality and very stable and long-term filtration operation.
View all Pretreatment products
The largest portfolio of sulfate removal membranes in the market
DuPont introduced the first patented nanofiltration (NF) membranes for sulfate removal in the North Sea in 1987. Our ion-selective NF membranes have been used for over 20 years to treat seawater prior to injection into oil reservoirs. They remove sulfates to prevent and control reservoir scaling and souring.
Sulfate removal units (SRUs) employing NF membranes offer two main advantages in injection water treatment:
- The removal of sulfate eliminates the primary constituents from injection water that cause scale formation, thus reducing and eliminating this scaling problem.
- Hydrogen sulfide may be produced by chemical reduction of dissolved sulfate by sulfate-reducing bacteria, causing souring inside oil wells. By removing sulfate from injection water, hydrogen sulfide cannot be produced. This will reduce the potential for souring inside the wells.
The FilmTec™ SR90 product line is the best way to remove sulfates from seawater used for injection operations.
FilmTec™ Fortilife™ SR90
FilmTec™ Fortilife™ SR90 elements are specifically designed to handle biofouling in sulfate removal systems in oil production. These elements are equipped with advanced fouling resistance and cleanability features, helping plants reduce the number of cleanings while maintaining high sulfate rejection and permeability. With FilmTec™ Fortilife™ SR90 elements, operators can expect to improve SRU operations by reducing maintenance costs and downtime on offshore platforms. This is made possible by:
- Fouling-resistance technology reducing cleanings by 50%
- Low differential pressure
- Durable membrane chemistry
- More effective and efficient cleaning of biofilm and organic compounds
To learn more about FilmTec™ Fortilife™ SR90 elements, please contact us.
View all Sulfate Removal resources
Reverse osmosis and nanofiltration to achieve successful low-salinity injection water
Low-salinity water injection is a popular enhanced oil recovery technique that has gained popularity the past decade. Using low-salinity water to inject into aging oil reservoirs results in enhanced oil recovery compared to using high-salinity water. The salinity level typically used in this low-salinity management strategy is 0.1% to 1%. DuPont offers a range of RO and NF membranes that can achieve the desired water quality for successful low-salinity injection.
View all Desalination products
-
Pretreatment+
Pretreatment with ultrafiltration for reliable downstream operation
Proper pretreatment is a key factor for successful long-term performance of sulfate removal units (SRUs). Reliable pretreatment can remove particles, algae, bacteria, and sand to provide effective and stable operation downstream, reducing downtime. DuPont offers a variety of ultrafiltration (UF) products that are advantageous in meeting these needs.
DuPont offers UF in two different configurations: multi-element vessel (MEV) or single-element racks. The MEV system uses a pressure vessel with an adaptor to hold multiple UF modules operating in parallel. This reduces the amount of space needed and eliminates the need for piping manifolds. DuPont also offers UF cartridges that can fit into standard horizontal pressure vessels that are organized similarly to an RO system. This offering is a more flexible option for pre-built systems.
DuPont also offers UF modules with either polyvinylidene fluoride (PVDF) or polyethersulfone (PES) fibers. PVDF membranes are most common in oil & gas applications as they offer high chemical tolerance and are tolerant to temperature variations, promoting longer module life. Hollow-fiber PVDF membranes provide exceptionally high filtrate quality and very stable and long-term filtration operation.
View all Pretreatment products
-
Sulfate Removal Nanofiltration+
The largest portfolio of sulfate removal membranes in the market
DuPont introduced the first patented nanofiltration (NF) membranes for sulfate removal in the North Sea in 1987. Our ion-selective NF membranes have been used for over 20 years to treat seawater prior to injection into oil reservoirs. They remove sulfates to prevent and control reservoir scaling and souring.
Sulfate removal units (SRUs) employing NF membranes offer two main advantages in injection water treatment:- The removal of sulfate eliminates the primary constituents from injection water that cause scale formation, thus reducing and eliminating this scaling problem.
- Hydrogen sulfide may be produced by chemical reduction of dissolved sulfate by sulfate-reducing bacteria, causing souring inside oil wells. By removing sulfate from injection water, hydrogen sulfide cannot be produced. This will reduce the potential for souring inside the wells.
The FilmTec™ SR90 product line is the best way to remove sulfates from seawater used for injection operations.
FilmTec™ Fortilife™ SR90
FilmTec™ Fortilife™ SR90 elements are specifically designed to handle biofouling in sulfate removal systems in oil production. These elements are equipped with advanced fouling resistance and cleanability features, helping plants reduce the number of cleanings while maintaining high sulfate rejection and permeability. With FilmTec™ Fortilife™ SR90 elements, operators can expect to improve SRU operations by reducing maintenance costs and downtime on offshore platforms. This is made possible by:
- Fouling-resistance technology reducing cleanings by 50%
- Low differential pressure
- Durable membrane chemistry
- More effective and efficient cleaning of biofilm and organic compounds
To learn more about FilmTec™ Fortilife™ SR90 elements, please contact us.
View all Sulfate Removal resources
-
Desalination for Low-Salinity Injection+
Reverse osmosis and nanofiltration to achieve successful low-salinity injection water
Low-salinity water injection is a popular enhanced oil recovery technique that has gained popularity the past decade. Using low-salinity water to inject into aging oil reservoirs results in enhanced oil recovery compared to using high-salinity water. The salinity level typically used in this low-salinity management strategy is 0.1% to 1%. DuPont offers a range of RO and NF membranes that can achieve the desired water quality for successful low-salinity injection.
View all Desalination products
Find products for injection water treatment
View a list of innovative products for injection water treatment.
Injection Water Treatment Products
