DuPont™ Tyvek CommercialWrap® D
Durable Air and Water-Resistive Barrier Engineered to Improve Drainage and Stand Up to the Commercial Job Site
DuPont™ Tyvek CommercialWrap® D
Durable Air and Water-Resistive Barrier Engineered to Improve Drainage and Stand Up to the Commercial Job Site
<br><b>DuPont™ Tyvek® CommercialWrap® D</b> offers superior drainage and durability for commercial buildings. It features a specially engineered surface texture that provides enhanced water drainage under a wide variety of faces in climates the may require additional drainage. <br><br> <b>Tyvek® CommercialWrap® D</b> is made from 100% flash spunbonded high-density polyethylene fibers which have been bonded together by heat and pressure, without binders or fillers, into a tough durable sheet structure. Additives have been incorporated into the polyethylene to provide ultraviolet light resistance.
Resources
Product Information Sheets Installation Guides Technical Documents Brochure Codes & Certifications Guide Specifications Fire Performance Warranty
Features & Benefits
Energy Efficient
- Contributes to a more durable, sustainable structure.
- Maintains superior moisture control to help reduce energy costs.
High Performance Durability
- Helps meet challenges of heavy rainfall, windblown water, snow and humidity.
- Prevents water intrusion and accumulation which can lead to mold and water damage.
- Specially engineered grooves offer enhanced drainage.
- Tough and tear-resistant, ensuring durability and the ability to withstand high wind loads, making it ideal for commercial construction site conditions.
Temperature and UV Resistance
- Withstands up to nine months (270 days) of UV exposure.
- Maximum in-service temperature of 180° F.
Air and Water Barrier Performance
- Offers an ideal combination of enhanced drainage, air and water holdout, plus vapor permeability.
- Exceeds ABAA, ASHRAE 90.1, and IECC air leakage requirements (ASTM E2357).
- Water infiltration resistance up to 15psf, when tested in accordance with ASTM E331.
- Meets ASTM E2556, Type II standards for vapor permeable flexible sheet water-resistive barriers.
- Offers > 98% drainage efficiency when tested in accordance with ASTM E2273.
Specifications
Standard Sizes
Testing
<b>Tyvek® CommercialWrap® D</b> exhibits the properties and characteristics indicated in the table below when tested as represented. Review all instructions and (Material) Safety Data Sheet ((M)SDS) before use. Please contact your local DuPont™ Tyvek Specialist before writing specifications around this product. Product properties are as follows:
cfm/ft2 @ 1.57 psf
@ 1.57 psf
@ 1.57 psf
@ 1.57 psf
Smoke Developed = 25
<20 MJ/m2
<18 MJ/kg
lbs/in
Pass
Pass
Tested to 15 psf
30 perms
FAQ
Can DuPont™ Tyvek® Fluid Applied Flashing and Joint Compound+ or DuPont™ Sealant for Tyvek® Fluid Applied System be applied to the exterior sheathing when Tyvek® CommercialWrap® D is installed as the air and water barrier? Yes, when the architect-of-record, specifier, and/or building envelope consultant requires the exterior sheathing seam be treated prior to the installation for DuPont™ Tyvek® CommercialWrap® products, DuPont™ Tyvek® Fluid Applied Flashing and Joint Compound+ or DuPont™ Sealant for Tyvek® Fluid Applied System may be used.The professional installer must allow the Fluid Applied products to cure for a minimum of 48 hours prior to installing the Tyvek® CommercialWrap™ products. What’s the difference between DuPont™ Tyvek® CommercialWrap® D and DuPont™ Tyvek® DrainWrap™? Each of the WRBs help with drainage, with both having a 98% or greater drainage efficiency per ASTM E2273. The major difference between the two WRBs is the UV exposure. Tyvek® CommercialWrap® D can be left exposed for 9 months while Tyvek® DrainWrap™ has a 4-month UV exposure. These UV exposure limits were designed for the products applications. CommercialWrap® D is typically used on commercial projects while DrainWrap™ is used on residential projects. For additional information regarding application and use refer to the installation guidelines for the applicable project type. Can DuPont™ CommercialWrap® D be used as an intervening layer with DuPont™ Tyvek® Fluid Applied WB+™? DuPont™ Tyvek® CommercialWrap® products can be used as an intervening layer over DuPont™ Tyvek® Fluid Applied WB+™ with stucco façade.An intervening layer of Tyvek® building wrap can be installed after Tyvek® Fluid Applied WB+™ has cured for 24 hours. Can DuPont™ Tyvek CommercialWrap® D be used under brick? Yes. It is perfectly acceptable to use DuPont™ Tyvek® CommercialWrap® D under brick. It is also acceptable to use Tyvek® HomeWrap® and Tyvek® CommercialWrap® in this application. When using Tyvek®WRBs under brick, it is important to follow the brick manufacturer’s guidelines regarding the use of an air space between the brick veneer and sheathing. Typically, this space is 1-2 inches, and will act as a drainage plane if incidental moisture penetrates the brick, in addition to ventilating behind the cladding, which aids in drying of the wall assembly.
