DuPont™ Thermax™ XARMOR™ (ci) Exterior Insulation
Toughest, Most Durable Polyiso Insulation for the Thermax™ Wall System
DuPont™ Thermax™ XARMOR™ (ci) Exterior Insulation
Toughest, Most Durable Polyiso Insulation for the Thermax™ Wall System
<br><b>DuPont™ Thermax™ XARMOR™ (ci) Exterior Polyisocyanurate Insulation</b> is the toughest insulation for the patented Thermax™ Wall System. Designed for continuous insulation, <b>Thermax™ XARMOR™ (ci)’s</b> glass-fiber-reinforced polyisocyanurate foam core is homogenous – featuring finer cell size and better cell orientation, reducing voids and knit lines – resulting in one of the highest R-values available for immediate insulation and weather protection on the job site, as well as long-term thermal performance. <br><br> <b>Thermax™ XARMOR™ (ci) Insulation</b> is also the only Thermax™ Insulation with a dark exterior facer optimized to go behind rain screen exteriors. Its integral, durable thermoset-coated aluminum facer provides a drainage plane, water-resistive barrier and exterior sheathing; eliminating the need for a membrane, building wrap or exterior gypsum. Boasting a strong 4.0 mil embossed, acrylic-coated exterior foil facer, <b>Thermax™ XARMOR™ (ci) Insulation</b> provides builders with more durability for long-term performance. <br><br> With its low perm rating and high insulating value, <b>Thermax™ XARMOR™ (ci) Insulation</b> can help reduce the potential for condensation within the wall assembly. Thermax™ is also manufactured using a distinct free-rise technology using a unique fiberglass core for better product consistency, durability and fire performance than generic polyisocyanurate insulations.
Resources
Product Information Sheets Installation Guides Substitution Package Brochure Case Study Fire Performance Warranty
Features & Benefits
Ease of Installation
- Eliminates the extra step of installing a membrane or building wrap when used with DuPont™ LiquidArmor™ and DuPont™ DuraGard CM™.
- Designed for installation behind rain screen exteriors.
- Is lightweight, easy to cut, handle and install.
High Performance Durability
- Provides air and water protection.
- R-Value of 6.9 at 1" thickness.
Moisture Resistant and UV Stability
- Helps reduce the potential for condensation within the wall assembly.
- Contains UV-stable technology – can remain uncovered up to six months.
- Pressure washable up to 1,000 psi.
Specifications
Standard Sizes
Note: Please be advised that additional sizes may be available. Availability of all sizes varies by region and is subject to change. For further information, please contact your local DuPont Sales Representative or call us at 1-866-338-7668.
Testing
<b>Thermax™ XARMOR™ (ci) Insulation</b> exhibits the properties and characteristics indicated in the table below when tested as represented. Review all instructions and (Material) Safety Data Sheet ((M)SDS) before use. Please contact DuPont at 1-833-338-7668 when additional guidance is required for writing specifications that include this product.
Smoke Developed ≤ 450
Core and Finished Product
1Calculated flammability values for this or any other material are not intended to represent hazards that may be present under actual fire conditions.
2See Jensen Hughes engineering judgement
Code Compliance
<b>Thermax™ XARMOR™ (ci) Insulation</b> complies with the following codes:
FAQ
What sets DuPont™ Thermax™ XARMOR™ (ci) Exterior Insulation apart from other Thermax products? Boasting a strong 4.0 mil embossed, acrylic-coated exterior foil facer, Thermax™ XARMOR™ (ci) provides builders with more durability for long-term performance. Thermax™ XARMOR™ (ci) is also the only Thermax™ insulation with a dark exterior facer optimized to go behind rain screen exteriors. In the USA, a 20-year limited thermal warranty is available. When used as a component in the Thermax™ Wall System, a 15-year limited water-resistance warranty is also available. Can DuPont™ Thermax™ Brand Insulation be left exposed to the building interior? Thermax™ Brand Insulation products can be left exposed to the building interior (i.e., without a thermal barrier such as 1/2 inch gypsum wallboard) in specific non-rated ceiling assemblies or non-rated construction in commercial, industrial and agricultural buildings. Thermax™ Brand Insulation products cannot be left exposed to exterior conditions.
The use of Thermax™ Brand Insulation exposed to the building interior is documented with a Code Compliance Research Report (CCRR-0440).
NOTE: Thermax™ cannot be used as a duct work or plenum insulation- it does not meet the IBC /IMC for flame spread of 25 or less and smoke developed of 50 or less
How much does DuPont™ Thermax™ XARMOR™ (ci) Exterior Insulation weigh? 0.216 lb/ft2
To get weight of 1 inch x 4 feet x 8 feet board multiple the value by 32
Example: Thermax™ XARMOR™ (ci) Insulation 1in x 4ft x 8ft weighs (0.216 x 32) = 6.9 lbs What are the ASTM C1289 classifications for DuPont polyisocyanurate products ? The ASTM C1289 classifications for DuPontpolyisocyanurate products are as shown below:
Type1 - Faced with aluminum foil on both major surfaces of the core foam. Class 1 - Non-reinforced core foam. Class 2 - Glass fiber reinforced core foam. Dimensional stability will be greater than Class 1 when fastened properly. ASTM C1289 Class 2 exceeds Class 1 requirements.
